Billets

The billet manufacturing process allows the production of steel with a low content of impurities and non-metallic inclusions.
Steel grades can be made to customer specifications, subject to a feasibility study.

Product description

Low- and medium-carbon content steel billets suitable for the production of steel intended for the following applications:

  • Rolling of sections of various shapes and sizes for different structural and non-structural applications;
  • Reinforced concrete;
  • Wire rod.

Certification

Certified to EN 10204, point 2.2,  proving conformity with the technical data sheet.

Alfa Acciai
Acciaierie di sicilia
-

Range of dimensions

Billets with a square section of 130x130 mm and 160x160 mm

Length from 5 to 12 m.

Labelling

Each billet bears:

  • The heat number at the butt end or the back of the billet
Billets

Trade names

Billets

Geometrical features

Cross section Length
Square 130/160 mm 5-12 m ± 100 mm

Dimensional tolerances

Side Diagonal Straightness Twisting
+/- 2 mm ± 3% < 1°/m

Chemical characteristics

The table below shows the composition range of our billets:

C % Mn % Si % P % S % Cu % Sn % Cr % Ni % Mo % N % Ceq %
Min Max 0,040,65 0,351,5 0,050,6 < 0,050 < 0,050 < 0,80 < 0,050 < 0,25 < 0,30 < 0,07 < 0,012 < 0,50

Sales Organisation

For any information please contact Mr UBALDO DRAGANI
Phone: +39 030 23911 / E-mail: u.dragani@alfaacciai.it

Range of dimensions

Billets with a square section of 130x130 mm
Length from 6 to 12 m

Labelling

Each billet bears:

  • The heat number at the butt end or the back of the billet
Billets

Trade names

Billets

Geometrical features

Cross section Length
Square 130 mm 11 m ± 100 mm

Dimensional tolerances

Side Diagonal Straightness Twisting
-3 / +2 mm ± 1,8% < 5 mm/m at the butt ends
< 40 mm distributed
< 5°/m, max 15° on the entire length

Chemical characteristics

The table below shows the composition range of our billets:

C % Mn % Si % P % S % Cu % Sn % Cr % Ni % Mo % N % Ceq %
Min Max 0,150,22 0,600,85 0,150,25 < 0,050 < 0,050 < 0,80 < 0,050 < 0,25 < 0,30 < 0,07 < 0,012 < 0,50

Sales Organisation

For any information please contact Mr UBALDO DRAGANI
Phone: +39 030 23911 / E-mail: u.dragani@alfaacciai.it
